Description

FBT dual channel power amplifiers are designed for power and reliability. The range includes models from 400w per channel through to 1500w per channel. They can be run in bridge mode.

AX800
FBT Dual Channel Power Amplifier
2 x 250W at 8 Ohms
2 x 400W at 4 Ohms
800W Bridged into 8 Ohms
Class AB
XLR Inputs and jack thru connectors
Speakon and Binding Post Outputs
Short circuit and thermal protection
Three position sensitivity switch (26-29-32dB)
Stereo-Bridge-Parallel Operation
Switchable Limiter
Fan cooled
Front panel attenuators
2RU

AX1200
FBT Dual Channel Power Amplifier
2 x 350W at 8 Ohms
2 x 600W at 4 Ohms
1200W Bridged into 8 Ohms
Class H
XLR Inputs and jack thru connectors
Speakon and Binding Post Outputs
Short circuit and thermal protection
Three position sensitivity switch (26-29-32dB)
Stereo-Bridge-Parallel Operation
Switchable Limiter
Fan cooled
Front panel attenuators
2RU

AX2000
FBT Dual Channel Power Amplifier
2 x 650W at 8 Ohms
2 x 1000W at 4 Ohms
2000W Bridged into 8 Ohms
Class H
XLR Inputs and jack thru connectors
Speakon and Binding Post Outputs
Short circuit and thermal protection
Three position sensitivity switch (26-29-32dB)
Stereo-Bridge-Parallel Operation
Switchable Limiter
Fan cooled
Front panel attenuators
2RU

AX3000
FBT Dual Channel Power Amplifier
2 x 950W at 8 Ohms
2 x 1500W at 4 Ohms
3000W Bridged into 8 Ohms
Class H
XLR Inputs and Thru connectors
Speakon Outputs
Short circuit and thermal protection
Three position sensitivity switch (26-29-32dB)
Stereo-Bridge-Parallel Operation
Switchable Limiter
Fan cooled
Front panel attenuators
2RU
